Automatic water softening filter with iron removal function „Aquaphor“ S550
AQUAPHOR S550 Water Softener
High-quality compact water softening filter with iron removal function. AQUAPHOR S550 ensures effective water softening and iron removal for residential and small commercial premises.
Technical Specifications
| Model | AQUAPHOR S550 |
|---|---|
| Product Type | Compact water softening filter with iron removal function |
| Maximum Capacity | 1100 g |
| Maximum Compensated Hardness | 1200 mg/l |
| Iron and Manganese Concentration | Up to 10 mg/l (iron up to 0.3 mg/l, manganese up to 0.1 mg/l after treatment) |
| Minimum pH Value | 6 |
| Water and Ambient Temperature | +5...+38 °C |
| Water Pressure | 0.14–0.7 MPa |
| Nominal/Maximum Flow Rate | 23/35 l/min |
| Pressure Loss at 22.7 l/min | 0.1 MPa |
| Regeneration Method | Intelligent, based on water meter |
| Power Supply | 12 VAC; 50/60 Hz; 0.015 kWh |
| Connection Ports (NPT) | 1" (MNPT) |
| Filtration Tank Size (ID × H) | 267 × 277 mm (W×D×H) |
| Overall External Dimensions | 322 × 432 × 554 mm (W×D×H) |
| Total Weight | 35 kg |
| Media Material | Superfine monodisperse ion exchange resin |
| Media Volume | 15 l |
| Quartz Sand | 0.8 kg |
| KDF85 (S550 P1 version only) | 0.35 l |
| HE Mode Capacity | 0.8 kg salt / 465 g hardness |
| HC Mode Capacity | 2.1 kg salt / 903 g hardness |
| AU Mode Maximum Capacity | 3.3 kg salt / 1100 g hardness |
| Regeneration Duration | 30-40 minutes |
| Minimum Drain Pipe Diameter | 16 mm (5/8") |
Key Features and Benefits
• Compact design with Superfine monodisperse ion exchange resin media
• Intelligent regeneration based on water consumption
• "Two-in-one" function - water softening and iron removal
• Economical salt and water consumption for regeneration
• Quiet operation due to unique tank design
• Media lasts up to 10 times longer than conventional systems
• Automatic control with LCD display and control buttons
• Reliable 12V power supply with energy saving features
• Easy maintenance and operation
Applications
• Private homes and cottages
• Small-scale commercial premises
• Offices and institutions
• Small hotels
• Cafes and restaurants
• Water quality improvement for domestic and business use
Design Features
• Unique tank design for quiet operation
• Superfine monodisperse ion exchange resin
• Quartz sand layer for additional filtration
• KDF85 media (in S550 P1 version) for enhanced iron removal
• Quality NPT threads for reliable connection
• Integrated water meter for accurate consumption measurement
• Programmable controller with LCD display
• Automatic bypass valve for emergency situations
Water Quality Requirements
• Water hardness: up to 24 mg-eq/l
• Ferrous iron: up to 10 mg/l
• Ferric iron: up to 0.3 mg/l
• Manganese: up to 3 mg/l
• pH value: 6-9
• Petroleum products: up to 1 mg/l
• Sulfur: up to 10 mg/l
• Permanganate oxidation index: up to 5 mgO₂/l
Regeneration Modes
• AU (Auto) mode: controller monitors daily water consumption and adjusts salt amount for regeneration
• HC (High Capacity) mode: fixed salt regeneration setting, allowing less frequent media washing
• HE (High Economy) mode: economical salt regeneration setting, significantly saving salt
• 96h mode: forced regeneration every 3-4 days if iron or manganese is present in water supply
Package Contents
• Fully assembled softener - 1 pc.
• Overflow fitting - 1 pc.
• Drain tube Ø16 mm (5/8"), L=2.5 m - 1 pc.
• Flexible hose 1" × 3/4" with sealing rings - 2 pcs.
• Power supply 12 VAC - 1 pc.
• Controller - 1 pc.
• Drain tube 1/2" - 1 pc.
Warranty and Service
• 2-year manufacturer warranty from purchase date
• Professional installation and service network
• Original spare parts and accessories
• Technical support and consultations
• Media service life up to 5 years
Note: Exact parameters and specifications are provided based on manufacturer's official documentation. It is recommended to perform water analysis and consult with specialists before installation.
